Unilumin Uslim II
Kampro
The Uslim II Series LED walls offer versatile applications. The variety of pixel pitches and module sizes enables flexible adaptation to your individual needs.
Unilumin Uslim II
Pixel Pitches: 1.5 mm - 1.8 mm - 2.5 mm - 3.9 mm - 4.8 mm
Technical Specifications
600 cd/m²
Brightness
7,680 Hz
Refresh Rate
3.2/5.6/10.5 kg
Weight
5,000:1
Contrast
Get the Highlights.
Features in Detail
High-resolution LED panels for many applications. Seamless installation and flexible configuration.
Rugged design for professional use. Easy maintenance and reliable operation.
Technical Specifications
Pixel Pitch
1.5 mm, 1.8 mm, 2.5 mm, 3.9 mm, 4.8 mm
Dimensions (cabinet)
W500mm × H250mm/500mm/1000mm × D40mm
Brightness
600 cd/m²
Aspect Ratio
1:0.5/1:1/1:2
Contrast
5,000:1
LED Type
3-in-1 SMD
Refresh Rate
7,680 Hz
Video Frame Rate
50/60 Hz
Protection Class
IP30
Resolution
320 x 160/320/640 px
Viewing Angle H
160°
Viewing Angle V
160°
Weight
3.2/5.6/10.5 kg
Service Access
Front & Back
Module Dimensions
250 × 250 mm
Certifications
Operating Temperature
-10 °C ~ +45 °C / 10–80% RH
