Unilumin USK
Kampro
Pixel Pitches: 2.6 mm - 2.9 mm - 3.9 mm - 4.8 mm - 5.9 mm
This is some text inside of a div block.
Unilumin USK
Pixel Pitches: 2.6 mm - 2.9 mm - 3.9 mm - 4.8 mm - 5.9 mm
Technical Specifications
Pixel Pitches
2.6 mm - 2.9 mm - 3.9 mm - 4.8 mm - 5.9 mm
Dimensions
500 x 750/1000 x 78 mm
Brightness
6,000 cd/m²
Aspect Ratio
1:2 / 2:3
Contrast
4,000:1
LED Type
3-in-1 SMD
Refresh Rate
7,880 Hz
Video Frame Rate
50/60 Hz
Protection Class
IP66
Resolution
192 x 288/384 px
Horizontal Viewing Angle
160°
Vertical Viewing Angle
140°
Weight
34/37 kg/m²
Service Access
Front & Rear
Module Dimensions
250 × 250 mm
Max. Power Consumption
580–650 W/m²
Typical Power Consumption
193–217 W/m²
Pixel Density
Certifications
CCC / CQC / CE / CB / UL / FCC / UKCA / BS476 / IP69K
Signal Inputs
Operating Temperature
6,000 cd/m²
Brightness
7,880 Hz
Refresh Rate
34/37 kg/m²
Weight
4,000:1
Contrast
Get the Highlights.
Features in Detail
High-resolution LED panels for many applications. Seamless installation and flexible configuration.
Rugged design for professional use. Easy maintenance and reliable operation.
Application Examples
No items found.
Technical Specifications
Pixel Pitch
2.6 mm - 2.9 mm - 3.9 mm - 4.8 mm - 5.9 mm
Dimensions (cabinet)
500 x 750/1000 x 78 mm
Brightness
6,000 cd/m²
Aspect Ratio
1:2 / 2:3
Contrast
4,000:1
LED Type
3-in-1 SMD
Refresh Rate
7,880 Hz
Video Frame Rate
50/60 Hz
Protection Class
IP66
Resolution
192 x 288/384 px
Viewing Angle H
160°
Viewing Angle V
140°
Weight
34/37 kg/m²
Service Access
Front & Rear
Module Dimensions
250 × 250 mm
Certifications
CCC / CQC / CE / CB / UL / FCC / UKCA / BS476 / IP69K
